FAIRFAX 3
DESCRIPTION
The Fairfax and Terra Linda make up our Fitness line, built for the flat-bar fitness road rider with the accessory mounts and gear range for future upgrades.
SPECIFICATIONS
- Intended Use- Commuting
- Wheel Size- 700c
- Braking System- Hydraulic Disc
- Frame Material- Aluminium
- Fork Material- Carbon
- Frame- Series 3 Fitness, 6061 Aluminum, 700C Wheels, Relieved Tapered Head Tube and BB, Internal Cable Routing, Disc Specific Forged Dropouts, Fender, Rack, and Kickstand Mounts
- Fork- Marin Full Carbon w/ Tapered Steerer, Fender Eyelets
- Bottom Bracket- Sealed Cartridge Bearings, Square Taper
- Chain- KMC X9
- Crank- Forged Alloy, 48/32T Chainrings, Ring Guard
- Shift Levers- MicroSHIFT R9 2x9 Flat Bar Road Shifters
- Cassette- Shimano, 9-Speed, 11-34T
- Front Derailleur- MicroSHIFT R9
- Rear Derailleur- Shimano Sora
- Grips/Bartape- Marin Ergonomic Locking
- Handlebar- Marin Alloy Flat
- Stem- Marin 3D Forged Alloy
- Saddle- Marin Fitness Plush
- Seatpost- Marin Alloy, 27.2mm
- Front Brake- Tektro HDM275 Hydraulic Disc, 160mm Rotor
- Rear Brake- Tektro HDM275 Hydraulic Disc, 160mm Rotor
- Front Wheel- Marin Aluminum Double Wall, 19mm ID, 25mm Tall, Disc Specific
- Rear Wheel- Marin Aluminum Double Wall, 19mm ID, 25mm Tall, Disc Specific
- Tire- Vee Tire, G-Sport, 700Cx35mm, Puncture Protection, Wire Bead
- Pedal- Commute Platform
XS | S | M | L | XL | |
A STACK | 557 | 571.3 | 590 | 609 | 637.3 |
B REACH | 385 | 400 | 420 | 440 | 455 |
C HEADTUBE ANGLE | 70.5° | 70.5° | 70.5° | 70.5° | 70.5° |
D HEADTUBE LENGTH | 140 | 155 | 175 | 195 | 225 |
E SEATTUBE ANGLE | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
F SEATTUBE LENGTH | 380 | 430 | 480 | 520 | 550 |
G TOPTUBE EFFECTIVE | 550 | 569.2 | 594.8 | 620.4 | 643.8 |
H BB HEIGHT | 283.5 | 283.5 | 283.5 | 283.5 | 283.5 |
I BB DROP | 70 | 70 | 70 | 70 | 70 |
J CHAINSTAY | 445 | 445 | 445 | 445 | 445 |
K WHEELBASE | 1050.01 | 1070 | 1096.7 | 1123.4 | 1148.4 |
L STANDOVER HEIGHT | 660.74 | 705.38 | 745.2 | 780.34 | 809.68 |
M FORK OFFSET | 50 | 50 | 50 | 50 | 50 |
SEATPOST DIAMETER | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
HANDLEBAR WIDTH | 640 | 640 | 680 | 680 | 680 |
STEM LENGTH | 70 | 70 | 70 | 70 | 70 |
CRANK LENGTH | 170 | 170 | 175 | 175 | 175 |
